DEEPCOOL Gamer Storm PN750M 750W 80+ Gold ATX 3.1 Fully Modular Power Supply

Get Quote On Whatsapp

Price: Contact us on WhatsApp

  • PSU Category – Full Modular
  • Type – ATX12V V3.1
  • Maximum Power – 750 Watt
  • Efficiency – 90% Efficiency

SKU: deepcool-gamer-storm-pn750m-psu

Description

DEEPCOOL Gamer Storm PN750M 750W 80+ Gold ATX 3.1 Fully Modular Power Supply

Feature

GRACEFUL GOLD

Deepcool 80 Plus Gold certified to meet a high level of power efficiency under 90% of typical loads. Each unit is also rated Gold by Cybenetics.

FUTURE PROOF

With the ability to provide twice the total system power for 0.1 ms, random power spikes will never be an issue. The PN750M will provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.

Deepcool PN750M

POWER YOU CAN TRUST

Through the use of a main Japanese electrolytic capacitor, active PFC, full-bridge SRC LLC, and a DC-to-DC topology, the PN750M can keep the hold-up time to ≥ 16 ms under a high load of 80%.

Deepcool PN750M

PCI-E 5.1 POWER

Equipped with a high-grade 105C-resistant 16AWG copper-core embossed 12V-2×6 cable, the PN750M provides up to 450W for modern GPUs

Deepcool PN750M

SLEEVED CABLES

The PN750M has been outfitted with sleeved cables right out of the box! A welcomed upgrade to add to the premium asesthic and feel of the PSU.

Deepcool PN750M

DYNAMIC FDB FAN

The PN750M comes equipped with a dynamic 120mm FDB fan that will adjust its speed based on the cooling needs of the PSU.

Deepcool PN750M

HIGH QUALITY BUILD

Due to the high quality of the parts utilized, the PN750M will operate at altitudes up to 5000 meters above sea level.

EXCELLENT COVERAGE

The PN750M is engineered and manufactured at such a high level that DeepCool is offering a lengthy 10 years of trouble-free limited warranty coverage.

Specifications
Type ATX12V V3.1
Product Dimensions 150×140×86mm (W x L x H)
Efficiency certification 80Plus Gold
Fan Size 120mm
Fan Bearing FDB (Fluid Dynamic Bearing)
Topology Active PFC + Full Bridge SRC LLC + DC to DC
Capacitors Japanese Bulk Capacitor
Power Good Signal 100-150ms
Hold Up Time ≥16ms(80% Load)
Efficiency ≥90% Under Typical Load(50% Loading)
Protection OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature 0 – 40℃
Regulatory CE/FCC/CCC/cTUVus/RCM/EAC/BIS/TUV-RH
Erp Regulation ErP 2014
Environment Protection WEEE/中国 RoHS/Triman/P65
MTBF 100,000 Hours
